RD Upblast Roof Exhaust Fan 42 inch 32476 CFM Direct Drive 3 Phase RD42T30750CM
Canarm
Item #: RD42T30750CM
Blade Diameter
42.0"
CFM
32476
Phase
3 Phase
Voltage
208 / 230 / 460 AC
Specs for RD Upblast Roof Exhaust Fan 42 inch 32476 CFM Direct Drive 3 Phase RD42T30750CM
Amp: 24 / 21.8 / 10.9
Blade Diameter: 42.0"
Blade Material: Galvanized Steel
CFM: 32476
Dimensions: 34" x 47.5" x 47.5
Drive Type: Direct
Hertz: 60
Horsepower: 7 1/2
Made in the USA: No
Motor Type: TEFC
Phase: 3 Phase
RPM: 1140
Speed(s): 1 Speed
Voltage: 208 / 230 / 460 AC
Warehouse: New York
Warranty: 1 Year
NOTE: THESE FANS ARE SPECIAL NON-STOCK ITEMS AND CANNOT BE RETURNED OR CANCELLED.
FEATURESSturdily constructed direct drive roof exhausters for industrial and commercial applications.
Heavy duty galvanized blades.
Galvanized steel wind-band and rain-proof butterfly dampers.
Totally enclosed ball bearing motors.
Not recommended for dirty or dust laden applications
*dBA ratings shown are measured at 0" static pressure, and should be used as a guideline only.
The following file(s) are provided by the manufacturer.
