XBL Wall Mount Panel Type Exhaust Fan 30 inch 3 Phase 7730 CFM Belt Drive XBL30T30033M
Specs for XBL Wall Mount Panel Type Exhaust Fan 30 inch 3 Phase 7730 CFM Belt Drive XBL30T30033M
NOTE: FANS ARE SPECIAL NON-STOCK ITEMS AND CANNOT BE RETURNED OR CANCELLED.
Economy commercial and light duty industrial exhaust fans. Ideal for Factories, Warehouses, Gymnasiums, Greenhouses, etc. XBL series fans are typically used for low pressure applications with little or no duct work. The XBL series is constructed for efficient, economical operation and are designed to be used primarily as exhaust fans. These feature heavy gauge steel on the fan panel and post. ODP motors and durable baked on polyethylene powder coat finish are standard.
FEATURES
Heavy gauge steel fan panel with deep spun orifice and flared venturi to maximize efficiency.
Heavy steel post Motor mount with ‚ÄúU” clamp motor mount/belt tensioner.
ODP‚Äàmotors are standard.
Durable baked on textured polyethylene powder coat finish.
The following file(s) are provided by the manufacturer.
